betaling Type:L/C,T/T,D/P
Incoterm:FOB,CFR,CIF,EXW
vervoer:Ocean,Land,Express
Haven:Qingdao,Shanghai,Tianjin
Model: HC650/980DP
Standaard-: AiSi, ASTM, bs, DIN, GB, JIS
Plaats Van Herkomst: China
Soorten: Stalen plaat, Staalrollen
Productieproces: Koudgewalst
Toepassing: Ketelplaat, Container plaat, Schip plaat
Speciaal Staal: Slijtvast staal, Stalen plaat met hoge weerstand
Tolerantie: ± 1%
Categorie: Koudgewalste staalplaat, Laaggelegeerde plaat, Stalen plaat
Verwerkingsservice: Ponsen, Snijden, Decoiling, Lassen, Buigen
verpakkingen: Standaard mariene verpakkingen, of zoals vereist door de klant
produktiviteit: 10000 Tons Per Month
vervoer: Ocean,Land,Express
Ondersteuning over: 10000 Tons Per Month
Certificaat: ISO 9001
Haven: Qingdao,Shanghai,Tianjin
betaling Type: L/C,T/T,D/P
Incoterm: FOB,CFR,CIF,EXW
ASME Cold Rolled HC650/980DP staalbladen voor lichaamsveiligheidscomponenten zoals het middengedeelte van de binnenste platen voor de vloer/stoel Crossbalk/Botsbalk
| Dual Phase Steel: DP980, DP1180; Martensitic Steel: MS980 | |||||||||||||||||
|
Thick Width |
0.3 | 0.4 | 0.5 | 0.6 | 0.7 | 0.8 | 0.9 | 1.0 | 1.1 | 1.2 | 1.3 | 1.5 | 1.7 | 1.9 | 2.1 | 2.3 | 2.5 |
| 1000 | |||||||||||||||||
| 1050 | |||||||||||||||||
| 1150 | |||||||||||||||||
| 1250 | |||||||||||||||||
| 1350 | |||||||||||||||||
| 1450 | |||||||||||||||||
| 1500 | |||||||||||||||||
| 1650 | |||||||||||||||||
| Steel Grade | Y.S/MPa | T.S./MPa | EL./% | Safety parts | Hazardous parts |
| HC550/980DP | 600~720 | 980~1080 | 10~14 | Body safety components such as the middle section of the front floor sill inner plate, seat crossbeam, collision beam, etc | Parts with small forming angles such as anti-collision beams/rods and parts with larger flanges |
| HC650/980DP | 650~750 | 980~1100 | 9~13 | Door sill beams, seat rails, collision beams and other body safety components | Parts with small forming angles such as anti-collision beams/rods and parts with larger flanges |
| HC700/980DP | 750~840 | 1000-1100 | 8~11 |
Frame front crossbeam Seat rails, anti-collision beams, and other body safety components" |
Parts with small forming angles such as anti-collision beams/rods and parts with larger flanges |
| HC820/1180DP | 900~1130 | 1180~1290 | 5~7 | Door sill beams, collision beams, and other body safety components | Parts with small forming angles such as anti-collision beams/rods and parts with larger flanges |
| HC700/980MS | 720~840 | 1000-1110 | 8~11 | Body safety components such as crash beams, crash bars, etc | Parts with small forming angles such as anti-collision beams/rods and parts with larger flanges |
Verpakking en transport
